SunnySky XS High Power X8012S Brushless Motors

Description

Powerful Multirotor Motors
New patented XS appearance is design with excellent industrial vision. The semi-enclosed structure not only effectively prevent sands and sundries from getting into?motor, but also have better effects of ventilation and heat dissipation.

Advanced large-diameter EZO bearings
Advanced Japanese EZO bearings with large diameters ensure each XS motor run?stable, quiet, and have great longevity.

Hand wound
Ultimate manual winding is compact, neat, which ensure low internal resistance,?high efficiency and up to 90% coil space factor, and effectively increase maximum?continuous power of each XS motor.

Sunnysky ultimate manufacturing technology?
With Sunnysky ultimate manufacturing and particular assembling technology, XS?motors are made of great workmanship, precise dimensions, small shaft and radial?runouts. All of these make the motor run smoothly and reliably in the air.?

[TABS]OVERVIEW

KV150

Stator Diameter	80mm	Rotor Diameter	89.3mm
Stator Thickness	12mm	Shaft  Diameter	15mm
No.of Stator Slots	24	Body Length(without  shaft )	35mm
No.of Rotor Poles	28	Body Length	50.5mm
Motor Kv	150	Max Lipo Cell	12S
No-load current	1.3A/10V	ESC	80A
Motor Resistance	42mΩ	Recommended Prop(inch)	26*8.5
Max Continuous Current	63A/30s	Recommended single take-off weight	≤4500g
Max Continuous Power	2800W
Weight	470g



Prop(inch)	Voltage(V)	Amps(A)	Thrust(gf)	Watts(W)	Efficiency(g/W)	Load temperature in 100% throttle
26*8.5	44.4	1.7	1000	75	13.25	90℃
		4.1	2000	182	10.99
		7	3000	311	9.65
		10.7	4000	475	8.42
		14.8	5000	657	7.61
		19.2	6000	852	7.04
		24.3	7000	1079	6.49
		29.7	8000	1319	6.07
		35.8	9000	1590	5.66
		41.9	10000	1860	5.38
		49.3	11000	2189	5.03
		55	11750	2442	4.81
		55.8	11900	2478	4.80



[/TABS]
